ItalianoRevolving mechanism with wooden slats
This clever revolving mechanism with a simple and unique opening system converts into a bed. Seat and back cushions are fixed to the frame during the opening action. New Roller with wooden slats is supplied with bayonet joints, that allow an easy assembly and disassembly operation (arm and backrests and components) for a simple handling of the sofa bed.
New Roller with wooden slats is made of two independent sleeping surfaces. It is dedicated to people who need a customized tension adjustment with its 4 levels. The sleeping surface is made of WOODEN SLATS ( GREEN- ECO-FRIENDLY) that have various tension levels for a differentiated and adjustable sleeping surface.
| PRODUCT | A | B | Recommended mattress size |
| Mec 106 NEW ROLLER 182 | 182 | 165 | 160x196x13 |
| Mec 106 NEW ROLLER 162 | 162 | 145 | 140x196x13 |
| Mec 106 NEW ROLLER 142 | 142 | 125 | 120x196x13 |
| Mec 106 NEW ROLLER 122 | 122 | 105 | 100x196x13 |
| Mec 106 NEW ROLLER 92 | 92 | 75 | 70x196x13 |
We recommend to periodically lubricate the highlighted parts, and in particular the areas between rivets and levers, in order to avoid noises in the opening and closing of the mechanism. A silicone lubricant spray is recommended.
